Automatic Voltage Regulator AVR KI-DAVR-250S for Generator Genset Single Phase

Automatic Voltage Regulator AVR KI-DAVR-250S for Generator Genset Single Phase

Part Number:
KL-DAVR 250S
KI-DAVR-250S
KIDAVR250S

See Details:
Power & Sensing Input:
Voltage: 85 ~ 135 VAC / 190 ~ 240 VAC
Frequency: 50 / 60 Hz, Jumper selectable
Output:
Voltage: Max. 36 VDC @ 120 VAC input?? Max. 73 VDC @ 240 VAC input
Current:Continuous 4A????? Intermittent 7A for 10 sec??? (52 / 105VDC)
Resistance:Min. 15 ohm Max. 100 ohm
Voltage Regulation:
Voltage Build-up:Residual voltage at AVR terminal > 5 VAC
Operating Temperature: - 40C ~ 60C
Storage Temperature: - 65C ~ 85C
Burden: 250 / 500VA Max.
External Volts Adjustment: 5% with 1K ohm 1 watt trimmer???? 10% with 2K ohm 1 watt trimmer
EMI Suppression: Internal electromagnetic interference filtering
Unit Power Dissipation:
Max. 8 watt
Under Frequency Protection (Factory Setting)
60 Hz system presets knee point at 54 ~ 61 Hz
50 Hz system presets knee point at 45 ~ 51 Hz
Dimensions:148mm 80mm 47.5mm H
Weight: 262g 2%
