Generator Battery Charger 24V 10A DSE5100D
It is a electricizing charger with a float form, it has overcurrent protection,
short circuit protection, fails to charge up and a tiny electricizing function.
it has a function like electricizing quickly and safely. also you can regulate the current
automatically depends on different speed the speed of voltage increases
from different batteries during work. It represents the latest charging technology.
current: 6-12A
voltage: 12 V, 24 V
specification:
MODEL
GF240-1B-AM
EXIT
DC VOLTAGE
24 V
OUTPUT POWER
240 W
SCOPE OF CURRENT
0-10
GAIN and NOISE (max.)
240mVp-p
VOLTAGE ADJ. RANGE
10%
REGULATION LINE
0%
LOAD REGULATION
0%
VOLTAGE TOLERANCE
0%
CONFIGURATION, TIME OF ENTRANCE
800 ms, 50 ms at full load
HOLD THE TIME
60 ms
ENTRANCE
VOLTAGE RANGE
90-264VAC 110-260VAC
AC CURRENT (Typ.)
0.35A / 226VAC 0.18A / 240VAC
FREQUENCY RANGE
47-63Hz
PERFORMANCE (Typ.)
82%
CURRENT CURRENT (Typ.)
WINTER START 15A / 115VAC 30A / 230VAC
CURRENT CURRENT
PROTECTION
OVERLOAD
115% ~ 135% of the power rating; Pulsing hicuup closed, automatic recovery
OVER VOLTAGE
rated output voltage 105% ~ 150% start of protecion overvoltage
protection: burst mode, loading of abnormal conditions, automatic recovery
protection against ZWARCIEM
voltage input off and reset for recovers
ENVIRONMENT
WORKING TEMPERATURE.
-0 45 (Refer to the load output curve derating)
WORK HUMIDITY
20 ~ 90% RH without condensation
STORING TEMPERATURE, HUMIDITY
-20 85 10 ~ 95% RH
TEMP. COEFFICIENT
05% C
COOLING METHOD
BASED ON THE AIR CONVECTION
SAFTY and EMC
SAFTY STANDARDS
EN60950-1 CE Approved
HOLD VOLTAGE
I / P-O / P: 1.5 KVAC, P-FG: 1.5 KVAC, P-FG: 0.5 KVAC
RESISTANCE OF ISOLATION
I / P-O / P, P-FG, P-FG: 100 M Ohm / 500VDC
EMI WAY
compliance of EN55022
HARMONIC CURRENT
compliance EN61000-3-2, -3
EMS IMMUNITY
compliance of EN55024
OTHERS
TERMINAL CONNECTIONS
BRAND: AC-L, AC-N, FG, GND, GND, DC +, DC-
DIMENSION
L200 H49.5MM W111
SHEET MATERIAL
chassis: 2.0mm thickness of aluminum; Cover: 0.7mm thick iron (silvering)
