Details:
The DSE7510 is an Automatic Engine Control Module, designed to provide advanced load share functionality for diesel and gas generating sets that include electronic and non-electronic engines
The module load share functions include automatic synchronising with built-in synchroscope and closing onto dead bus. Direct and flexible outputs from the module are provided to allow connection to the most commonly used speed governors and automatic voltage regulators (AVRs)
A sophisticated module monitoring an extensive number of engine parameters, the DSE7510 will annunciate engine shutdowns, warnings, and engine status information on the back-lit LCD screen, by illuminated LED, on a remote PC, by audible alarm and via SMS text alerts (GSM modem required). The module includes RS232 and RS485 ports as well as dedicated terminals for system expansion
?
DC SUPPLY
CONTINUOUS VOLTAGE RATING
8 V to 35 V continuous
CRANKING DROPOUTS
Able to survive for 50 mS, providing supply was at least 10 V before dropout and supply recovers to 5 V. This is achieved without the need for internal batteries
MAXIMUM OPERATING CURRENT
460 mA at 12 V, 245 mA at 24 V
MAXIMUM STANDBY CURRENT
375 mA at 12 V, 200 mA at 24 V
CHARGE FAIL/EXCITATION RANGE
0 V to 35 V

OUTPUTS
OUTPUT A (FUEL)
15 A DC at supply voltage
OUTPUT B (START)
15 A DC at supply voltage
OUTPUTS C & D
8 A 250 V (Volt free)
AUXILIARY OUTPUTS E,F,G
2 A DC at supply voltage

GENERATOR
VOLTAGE RANGE
15 333 V AC (L-N)
FREQUENCY RANGE
3.5 Hz to 75 Hz

MAGNETIC PICK-UP
VOLTAGE RANGE
+/- 0.5 V to 70 V
FREQUENCY RANGE
10,000 Hz (max)

BUILT-IN GOVERNOR CONTROL
Fully Isolated
Minimum Load Impedance: 1000
Gain Volts - 10 V DC
Offset Volts - 10 V DC

BUILT-IN AVR CONTROL
Fully Isolated
Minimum Load Impedance: 1000
Gain Volts - 10 V DC
Offset Volts - 10 V DC

DIMENSIONS
OVERALL
240 mm x 172 mm x 57 mm
9.4?x 6.8?x 2.2?/strong>
PANEL CUT-OUT
220 mm x 160 mm
8.7?x 6.3?/strong>
MAXIMUM PANEL THICKNESS
8 mm
0.3?/strong>
