Regulator Automatic Governor for AVR EVC600C Universal Generator Voltage 180~250VAC

AVR EVC600C Universal Generator Voltage Regulator Automatic Governor 180~250VAC

Specification:
Voltage: Up To 90 [email protected]
Continuous Current: 8A
Maximum Instantaneous Output Current: 10ADC. ?0S
Minimum Excitation Winding Resistance: 8
Input Voltage (AC)
180-250Vac, 50/60Hz
Power: Up To 1000VA (240Vac)
Detection Voltage (AC)
180~250Vac (220Vac System), Single Phase, 50/60Hz;
350~480Vac(400Vac System), Single Phase, 50/60Hz;
Power Consumption: 5VA
Voltage Adjustment Range
[email protected] System; [email protected]
Voltage Regulation Accuracy ? 1%
Voltage Drift
Response Time: 1.5S
The Residual Excitation Voltage Of The Generator Is Automatically Built, 5Vac, 25Hz
Power Consumption: Up To 40W
CT: Rated Current Ratio 5A
Ordinary Current Transformer Drop0~6%, 0.8 Power Factor
Operating Temperature
-30C~+800C
Vibration
12Gs, 5-26Hz;
0.036 Inch Amplitude, 27~52Hz;
5.0Gs, 53~1000Hz
Shock
20Gs On Three Orthogonal Planes
Installation Location
Mounting The Junction Box Of The Generator With M4 Bolts
