Filter Element 130306360 for Perkins 102.04 103.15 104.19 1103A-33 1103C-33 402D-05 403C-07 404D-22

Filter Element 130306360 for Perkins 102.04 103.15 104.19 1103A-33 1103C-33 402D-05 403C-07 404D-22

Part number:130306360

Part name:Perkins Pre-Fuel/Water Separator Filter

Description:Filters or strainers 130306360 designed to be installed on the inlet side of the fuel pump to remove the debris that could damage the fuel pump,but not cause a reduction in pressure that could lead to cavitation and damage to the fuel pump. These filters have larger micron ratings than the main or secondary fuel filter.

Applications:
Fit For Perkins Engine:
100 Series: 102.04,102.05,103.06,103.07,103.09,103.10,103.11,103.13,103.15,104.19,104.22
1100 Series: 1103A-33,1103A-33T,1103C-33,1103C-33T,1103D-33,1103D-33G,1104A-44,1104A-44T,1104C-44,1104C-44T,1104C-44TA,1104D-44T
400 Series: 402C-05,402D-05,403C-07,403C-11,403C-15,403C-17,403D-07,403D-11,403D-15,403D-15T,403D-17,403F-11,403F-15,403F-15T,404A-22,
404C-15,404C-22,404C-22T,404D-15,404D-22,404D-22T,404D-22TA,404F-22,404F-22T

Specification:
External diameter (in):0.9
External diameter (mm):22
Integrated water trap:No
Length (in):1.7
Length (mm):42
Primary or Secondary:Primary
Type:Screen
